Home > Products > Ore Dressing Machine > Stirring TankStirring Tank
- supply Ability:1 Set/Sets per Week
- Port:Qingdao,Tianjin, Shanghai or others
- Type:agitation vat
- Application:Used as ore beneficiation
- Place of Origin:Henan China (Mainland)
- Brand Name:Hongxing
- Model Number: HX
- Type: Impact Pulverizer
- Certificate:ISO9001:2008
- Warranty: 12 Months
- Color: Orange/ green
- Installation:under engineer's guidance
Agitation vat is one machine with the appearance of cylinder, and one main function of it is to mix one or more material. Agitation vat is regarded as the mixing of mineral pulp and pharmacy in order to make the material and pharmacy being reacted in the ore dressing process and to prepare for the ore dressing process in the later. The so-called mine mixing bucket or mineral mixing barrel called by the human beings in the daily life is just this machine above on.
Agitation vat is also called aggregate mixer or stirring tank.The so-called mine mixing bucket or mineral mixing barrel called by the human being in the daily life is just this machine above on.
This machine is driven by the electric rotor bringing the rotation of the impeller, and the mineral pulp and pharmacy is being put in the cylinder in order to realize the sufficient mixing in the process of the rotation of the impeller, which is one symbol of finishing the mixing work.
Product Gallery
Technical parameters of
Stirring Tank
| Specification | Chute inner dimension | Effictive cubage | Mixer | Motor | Total weight(kg) | |||
| Diameter(mm) | Depth | (m³) | Diameter(mm) | Rotate speed(r/min) | Model | Power(kw) | ||
| (mm) | ||||||||
| XB-750 | 750 | 750 | 0.26 | 240 | 530 | Y90S-4 | 1.1 | 550 |
| XB-1000 | 1000 | 1000 | 0.58 | 240 | 530 | Y90L-4 | 1.5 | 700 |
| XB-1200 | 1200 | 1200 | 1.14 | 400 | 320 | Y100L2-4 | 3 | 980 |
| XB-1500 | 1500 | 1500 | 2.2 | 400 | 320 | Y100L2-4 | 3 | 1330 |
| XB-2000 | 2000 | 2000 | 5.46 | 550 | 230 | Y132M2-6 | 5.5 | 2100 |
| XB-2500 | 2500 | 2500 | 11.2 | 650 | 200 | Y160L-6 | 11 | 3438 |
| XB-3000 | 3000 | 3000 | 19.1 | 700 | 210 | Y225S-8 | 18.5 | 5100 |
| XB-3500 | 3500 | 3500 | 30 | 850 | 230 | Y225M-8 | 22 | 7900 |
Note: Please enter your demand such as Raw material type, Capacity, Feeding material size, Final product size, etc. To become our quality clients will have access to a discount of contract!
