Home > Products > Sand Making Equipment > Belt ConveyorBelt Conveyor
- Supply Ability:2 Set/Sets per Week
- Port:Qingdao,Tianjin, Shanghai or others
- Type:Necessary Equipment
- Input Size:1.3-2.0 m/s
- Materials:Granite, basalt, quartz, iron ore, limestone, etc.
- Place of Origin:Henan China (Mainland)
- Brand Name:Hongxing
- Model Number: HX
- Certificate:ISO9001:2008
- Warranty: 12 Months
- Color: Orange / white
- Installation:under engineer's guidance
- Delivery Means: Container
Belt conveyor is also called conveyor belt, which is one key mining machine that can continuously convey materials.
Convey belt is mainly made up of the racks, belts, rollers, tensioning means and the drive means. In the process of conveying, the material can be put on the belt, which can be conveyed from one end to the other end by the force device. Convey belt can help to form one conveying process from the origin feeding place to the discharging place, which can convey the scattering material and the finished products. This machine also can form one flow process line with the rhyme according to the requirement on the craftsmanship of various mining industries except for the pure conveying materials.
Elevating conveyor belt can be used in the level transportation and tilt transportation, whose usage is very convenient, and which can be applied in the various modern industries such as the tunnel underground mining, the transporting system of mining surface, open exploration jobsites and ore dressing factory.
Hongxing mining machinery is one big manufacturing enterprise, and the mining belt equipment produced by our company can be specially designed for every client, it's our honor to welcome you to our company to choose every mining machine that you need.
Product Gallery
Technical parameters of
Belt Conveyor
| Belt width(mm) | Conveying length(m) Power(kw) |
Conveying speed(m/s) | Conveying amount(t/h) | ||
| 400 | ≤10 3 |
12-15 3-4 |
15-30 4-7.5 |
1.25-2.0 | 30-60 |
| 500 | ≤10 3 |
12-15 4-5.5 |
15-30 5.5-7.5 |
1.25-2.0 | 40-80 |
| 650 | ≤10 4 |
12-15 7.5 |
15-30 7.5-11 |
1.25-2.0 | 80-120 |
| 800 | ≤10 4 |
12-15 7.5 |
15-30 7.5-15 |
1.25-2.0 | 120-200 |
| 1000 | ≤10 5.5 |
10-20 7.5-11 |
20-40 11-22 |
1.25-2.0 | 200-320 |
| 1200 | ≤10 7.5 |
10-20 7.5-15 |
20-40 15-30 |
1.25-2.0 | 290-480 |
| 1400 | ≤10 11 |
10-20 15-22 |
＜20-40 22-45 |
1.25-2.0 | 400-680 |
| 1600 | ≤10 15 |
10-20 22-30 |
＜20-50 30-75 |
1.25-2.0 | 600-1080 |
| 1800 | ≤10 18.5 |
10-20 30-45 |
＜20-50 45-110 |
1.0-2.0 | 200-1500 |
| 2000 | ≤10 22 |
10-20 45-55 |
＜20-40 55-132 |
1.0-2.0 | 1000-2000 |
| 2400 | ≤10 30 |
10-20 55-75 |
＜20-40 75-185 |
1.0-2.0 | 1500-3000 |
Note: Please enter your demand such as Raw material type, Capacity, Feeding material size, Final product size, etc. To become our quality clients will have access to a discount of contract!
