Home > Products > Stone Crushing Equipment > Impact CrusherImpact Crusher
- Port:Qingdao,Tianjin, Shanghai or others
- Type:Secondary Crusher
- Input Size:250-500mm
- Hammer Texture:High chrome
- Application:Ore crushing, railway, highway, energy,etc.
- Place of Origin:Henan China (Mainland)
- Brand Name:Hongxing
- Model Number: HX
- Certificate:ISO9001:2008
- Warranty: 12 Months
- Color: Orange / white
- Installation:under engineer's guidance
- Delivery Means: Container
Impact crusher is also called impact breaker which is widely used in rock mining and quarrying and stone crushing. It is often seen in quarrying plant, ore beneficiation plant and power station and it is a important impact crushing machine.
During the rock mining process, the impact crusher is suitable for medium and fine crushing the rocks. After the materials are sent into the material feeding mouth through the feeding machine, they meet the impeller rotating with high speed, and impact to the impacting plate with high speed and are crushed. As a result, it can also be called mineral impact crusher or impact stone breaker.
The application of coal impact crusher in power plant: In the thermal power plant, the coal is often raw materials. Sometimes the size of the coal is too large and the burning is not complete, thus wasting the resources. For this reason, before the coal is burnt, it is first crushed in the impact coal mining equipment to make it smaller, and then the coal can be burned more sufficiently and the resources will be saved.
Impact Crusher for Sale
Hongxing Machinery, the famous stone crusher manufacturer in China, has high quality impact crusher for sale. Our impact crusher can process a variety of materials with side length of 100mm to 500mm, including granite, limestone, concrete, basalt, pebble, etc. Impact crusher for sale is widely used in ore crushing, railway, expressway, construction, artificial sand making and other industries. The commonly seen impact crusher models are PF-1520 impact crusher and PF-1315 impact crusher. Impact crusher price is depended on its models.
Hongxing Machinery is the large impact crusher manufacturing company in China. If you would like more information about our impact crusher price, please leave us a message below or send us an email to [email protected], thank you!
Product Gallery
Technical parameters of
Impact Crusher
| Model | Specification （mm） |
Feed opening （mm） |
The Maximum Feeding Size （mm） |
Capacity （t/h） |
Power （kw） |
Total weight （t） |
Overall dimension （L×W×H） （mm） |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 30-70 | 4P 37-45 | 12 | 2330×1660×2300 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-90 | 4P 45-66 | 15 | 2370×1700×2390 |
| PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-130 | 6P 110 | 17.7 | 2680×2160×2800 |
| PF-1214 | Φ1250×1400 | 400×1430 | 350 | 100-180 | 6P 132 | 22.4 | 2650×2460×2800 |
| PF-1315 | Φ1320×1500 | 860×1520 | 500 | 130-250 | 6P 200 | 27 | 3180×2720×2620 |
| PF-1320 | Φ1300×2000 | 993×2000 | 500 | 165-320 | 6P 250 | 34 | 3220×3100×2620 |
| PF-1520 | Φ1500×2000 | 830×2040 | 700 | 300-550 | 4P 315-400 | 50.6 | 3959×3564×3330 |
| PF-1820 | Φ1800×2000 | 1260×2040 | 800 | 600-800 | 6P 630-710 | 83.21 | 4400×3866×4009 |
Note: Please enter your demand such as Raw material type, Capacity, Feeding material size, Final product size, etc. To become our quality clients will have access to a discount of contract!
